Jacobsen HR 6010 parts

Rotary mowers from Jacobsen can be deployed in several ways. The HR 6010 is used in public green spaces and on sports fields. To keep a functioning machine, it is important to replace wear parts and ensure regular maintenance. RDM Parts ensures high quality parts that fit your HR 6010 are in stock. With parts numbers you can easily search online for your parts.

Replacement parts for Jacobsen HR 6010 Parts

Jacobsen HR-6010 Rotary Mower

Bushing

RDM-2190200

€22.64*

Pi

RDM-2216025

€50.92*

Hydrolic motor - fits for Ransomes HR6010 960 2218152-01

RDM-2218152-01

€1,535.74*

alkit

RDM-2300810

€103.37*

RDM-4129601

€110.55*

Washer

RDM-450393

€2.01*

Bolt

RDM-452626

€7.16*

Pi

RDM-MBF1969

€71.62*

Stopsolenoid

RDM-SSHR6010

€259.42*

Bus

RDM-W138024-02

€8.82*

Temp Sender

RDM-W148270

€187.19*

Muching blad

RDM-112243-02M

€57.80*

RDM-112243-03

€51.09*

Ring carrier Fits Ransomes Jacobsen 143031

RDM-143031

€52.65*

Roller

RDM-163425

€104.81*

teering joint

RDM-4205440

€47.71*

PIN - LYNCH HEAVY DUTY

R3290-384

€9.56*

BUSHING - CASTOR (See RDM-2190200)

R2190200

€50.30*

SPACER - CASTER

R4118731

€23.72*

Spacer - caster wheel

R101171

€25.57*

Bearing - castor wheel

R101172

€12.91*

Spacer - 3/4 x 4 1/4

R101176

€25.05*

Spacer - 3/4 x 1 x 1/2

R101177

€13.13*

washer R101170

R101170

€247.28*

1
2

Parts that fit the Ransomes HR6010

The different products for your HR6010 are easily found in the parts manual. If you don't have these documents, our parts specialist can help you to find the right parts for your machine. On our website you will find a clear overview of the products that are available for your Ransomes rotary mower. It is easier than an online parts lookup and you can directly request an offer for the parts that you need.

RDM Parts delivers original parts and alternatives to these parts for the Ransomes HR6010; o-ring sets, bolts, wheels and hydraulic pumps are part of our wide range of products. Our products are distinguished by their high quality for a good price. To make sure your Ransomes machine will be fully functioning as fast as possible, we deliver our products as fast as possible. If you need any assistance with finding the parts, feel free to contact us by phone, mail or Whatsapp. We will gladly help you to find the right replacement parts.

Maintenance for the Ransomes HR6010

You want to keep the total cost of ownership and the cost per hour of your HR6010 as low as possible. To realize this, you should give regular maintenance to your machine. This will result in a machine that is working properly and gives a high quality performance. A schedule can help you with organising this maintenance. This will help you clarify costs and hours that are put into the machine and gets you in control. A schedule is put together using the user manual and parts manual of the machine. Our product specialist can help with any questions regarding maintenance. If you take good care of your HR6010 it will result in less stalls. In turn this reduces the costs that is related to the operation of the machine. A clear maintenance schedule is favourable for your work schedule.

About the HR 6010

With a 60 horsepower turbo diesel engine this mower from Jacobsen / Ransomes is among the powerhouses of the machinery. The engine ensures that the power is supplied to the hydraulic motors from there the machine is powered. Every wheel has its own hydraulic motor which makes a 4 wheel drive system. With the 4 wheel drive, the machine is in much better shape to cope with the challenging conditions that is thrown at it. A servo motor devides the power by giving servos to the individual hydraulic motors when they are in need. This ensures optimal traction.

The Hr 6010 has one front deck and two side decks. The side decks can be retracted into the width of the machine. This makes for a compact machine (1.7m). The frontdeck of the machine is fully floating which enables it to follow the slopes of the terrain perfectly. The width of the frontdeck is 1,53 meters and it incorporates three blades that do the mowing. The machine has the option of choosing different side decks. Both variants of the side decks are fully floating, also following the terrain optimally. Before you order any wear parts for your side decks, please make sure that you know the exact type of the blade. Depending of the size of the deck, different blades fit. The wide side deck has the same blades as the front deck, the 530mm and incorporates a v-belt of 1720mm. The small type has mowing blades of 457mm and a belt of 1640mm. Both mowing decks have two blades per deck. Mulching blades also fit the decks.

De transportsnelheid van de HR 6010 is ongeveer 22 kilometer per uur als de machine rijdt op twee-wielaandrijving. Op het moment dat de maaidekken en de vier-wielaandrijving geactiveerd worden, heeft de machine een topsnelheid van 11 kilometer per uur. Dit zorgt voor een optimaal maaibeeld. Op deze snelheid heeft de machine een maaicapaciteit van ongeveer 3.6 hectaren per uur.

The topspeed of the HR 6010 is 22 kilometers per hour with the machine driving on two wheeled drive. When the mowing decks and 4 wheel drive are activated the machine has a topspeed of 11 kilometers per hour. This ensures an optimal mowing result with a mowing capacity of 8 acres.

How to reduce the costs of exploitation and the machine related costs of your HR6010?

With the use of parts from RDM Parts maintenance, exploitation and machine costs of your Ransomes 6010 can be drastically lowered. We sell alternatives for original parts and the original parts for a favourable price. This helps you to save on the costs of wear parts, maintenance parts and replacement parts. But the parts for the HR6010 do not only have a favourable price.

With machine like the HR6010 it is not only about the short term savings. Your machine is a long term investment as should the maintenance be. In the long run you want optimal results and that’s only possible with high quality parts. RDM Parts makes sure that product are of best quality standards. We produce some products ourselves when we think we can make it better and more durable. In the end the benefits of our parts lead to a machine that's maintained for less money that will run for a long time. This way you reduce the recurring costs that come with wear parts. You also reduce the general machine costs because maintenance, wages and stalling is reduced to a minimum.

The benefits of RDM Parts for your HR6010

Original and not OEM parts
Wide offer in brands
Best value for money
Online ordering
Parts specialist who are always ready for you

Find the right part fast
