RDM Parts Y-blade fitting for Noremat 103039

103039 y blades for noremat machines

Y blades are mostly used for less intensive mowing jobs with a flail mower. RDM Parts has several alternatives for the original with 103039 from noremat in the form of 808-63-ROU-54.

Mounting 808-63-ROU-54 y blades

Y blades are mounted on shackles on the flail mower. The 103039 y blades and our alternative 808-63-ROU-54 is often attached in pairs to a series of shackles or a chain. This ensures a larger range. The chain is mounted to an assembly point on a rotating roll in the mowing deck.

The difference between y-blades and flails

An y blade is better suited for lighter mowing jobs when compared to a flail. Both options give a nice mowing result. But a flail is bigger and is thus better suited for mowing other thick plants like bushes. At the same time a flail can also damage a tree, whilst this is harder with a y blade. Which one is better for you depends on the kind of mowing job you have in mind.

Specifications of the 103039 and the 808-63-ROU-54

RDM Parts also has the 808-63-ROU-54 Y-blade fitting for Noremat 103039 with an equal length as the original. The length of the part is 132 millimeter and this makes it a fitting alternative for the original. The width of the 808-63-ROU-54 is equal to the original. This Y-blade fitting for Noremat 103039 is 40 millimeter in width. The thicker a product is the more it can handle in terms of stress, can be taken as a general rule of thumb. 5 millimeter thick is the Y-blade fitting for Noremat 103039 from noremat with the original part number 103039. Since this is equal to the parts of RDM Parts, the 808-63-ROU-54 fits as an alternative for the original. The 808-63-ROU-54 and the original with are mounted with a mounting hole of 15 millimeter. With a bolt the part is attached through the mounting hole to the machine. Some of the parts have more than one mounting hole to mount it to the machine.

On what machines does the 808-63-ROU-54 fit?

Comparable to the original with number 103039 the 808-63-ROU-54 fits for the machines of noremat. The 808-63-ROU-54 is fitting for these parts: Noremat 103039, S.M.A. LA UNIV, and Rousseau 5.254.02.
