Jacobsen LF 100 Grass Basket Frame

Kies hier uw tekening

3 tekeningen beschikbaar

PIN - GROOVED 5/16 X 2 TYPE E

R461338

€ 3,57*

SPRING - TORSION LH

R353935

€ 67,66*

SPRING - TORSION RH

R353938

€ 67,66*

Fitting - grease 471214

R302-5

€ 1,02*

CAP - SWIVEL HOUSING

R345331

€ 3,25*

HOUSING - SWIVEL

R239066

€ 189,76*

PIN -

R361163

€ 3,57*

Screw - set - 5/16-18 x 3/8

R415521

€ 0,91*

Grass basket

R101530

€ 540,58*

#10

WASHER - FLAT 3/8 SAE Y/ZINC

R453011

€ 0,33*

#11

SPACER

R345510

€ 7,99*

#12

Washer - lock 3/8

R3254-6

€ 0,13*

#13

BOLT - HEX HD 3/8-16 X 1-1/4

R400264

€ 1,32*

#14

BRACKET - MOUNTING RH

R101532

€ 72,37*

#15

BOLT - HEX HD 1/4-20 X 3/4

R321-4

€ 0,86*

#16

Washer - flat 1/4

R453023

€ 0,36*

#17

WASHER - LOCK 1/4

R3253-3

€ 0,15*

#18

NUT - 1/4-20 YELLOW ZINC

R443102

€ 0,58*

#19

BRACKET - MOUNTING LH

R101531

€ 72,37*

#20

Yoke - lift assy rh / center

R122712

€ 424,96*

#21

As R313153

R313153

€ 733,44*

#22

Bushing

R3-0348

€ 10,73*

#23

BUSHING - CASTER ARM

R363539

€ 17,94*

#24

Arm - lift

R503566

€ 492,28*

#25

CLAMP - TORSION SPRING 1-3/8

R364902

€ 12,57*

#26

Yoke - lift assy lh

R122713

€ 422,39*

#28

Arm - lift center

R5000872

€ 512,31*

#29

Shaft - front lh

R163431

€ 128,11*

#30

SHAFT - FRONT RH

R163430

€ 128,11*
